Industrial-grade automatic rotary PU curing oven designed for high-efficiency thermal curing of polyurethane filter end caps and frames. Features 60 stations, variable-frequency rotation speeds, and precise digital temperature control. Once the PU adhesive is precisely cast using our Automatic Polyurethane PU Gluing Machine, the filters are transferred to this circular line to complete a highly uniform, automated curing cycle before final inspection.
This high-efficiency Automatic Rotary PU Curing Oven is a specialized thermal processing system engineered for the rapid, uniform curing of polyurethane (PU) foam adhesives after they are cast onto air filter end caps, panel frames, or industrial cabin filter elements. By circulating heated air along a continuous closed-loop turntable conveyor, it accelerates the chemical cross-linking and polymerization of PU resins, significantly shortening the manufacturing cycle.
Equipped with a 60-station circular turntable, digital multi-zone heating controls, and stepless variable-frequency speed regulation, this curing oven eliminates the bottleneck of manual filter handling and drying. It is the ideal auxiliary equipment for medium-to-large-scale air filter assembly lines, ensuring that every finished polyurethane air filter achieves a perfect hermetic seal, consistent elasticity, and high structural durability.
Technical Specifications
To ensure exact mechanical alignment with your polyurethane air filter production line, the technical parameters of the machine are detailed below:
Technical Parameters
Factual Specifications
Model
FP-RCO-60 (Automatic U-Type/Rotary Curing Line)
Number of Stations
60 Stations (Customizable to 40 / 70 / 80 stations)
Applicable Product
PU air filters, panel air filters, vehicle cabin filters
The machine features a continuous, heavy-duty circular turntable conveyor equipped with 60 independent processing stations. Operators only need to load the uncured, freshly glued filters at the loading station. After completing one full rotational cycle through the heated chamber, the fully cured, ready-to-pack filters return automatically to the same operator, eliminating labor bottlenecks.
2. Rapid Curing and Uniform Heat Distribution
Built with a highly insulated thermal curing chamber and a precise air-forced circulation system. By providing constant, uniform heat distribution (ambient up to 150°C) across the circular path, it reduces the PU adhesive curing time from the standard 30+ minutes at room temperature down to under 10 minutes.
3. Stepless Variable-Frequency Speed Regulation
Driven by a high-torque motor managed by a variable frequency drive (6–20 min/rotation), the rotation speed can be adjusted infinitely. This allows workshop managers to synchronize the curing cycle perfectly with the cycle speed of the preceding PU glue injection machinery.
4. Intelligent PLC & Centralized HMI
The centralized control panel enables real-time adjustments of conveyor rotation speeds, precise multi-zone heating temperatures, and pneumatic positioning pressures. Built-in alarms and temperature fluctuation monitors ensure high-repeatability and maximum operational safety.
Applications & Industrial Uses
This automated circular PU curing line is the essential thermal processing unit in assembly lines manufacturing:
Polyurethane (PU) Air Filters: Curing the injected PU foam end plates for passenger car, commercial vehicle, and agricultural machinery air filters.
HVAC Panel Filters: Curing the outer polyurethane sealing frames of cleanroom filters and air purifier elements.
Cylindrical Air Filters: Accelerating the adhesive bonding of heavy-duty industrial dust collector cartridges.
Why Partner with Fupei?
Strict Pre-Shipment Quality Inspections: Every rotary curing line is fully assembled and undergoes continuous running tests under actual operating temperatures at our factory to verify mechanical alignment and thermal stability before dispatch.
Custom Voltage & Grid Compatibility: We configure the internal electrical motors, heating elements, and PLC systems to meet your regional industrial standards (such as 3-Phase 380V/50Hz, 220V/60Hz, or 415V/50Hz) for rapid on-site commissioning.
Global Technical Assistance: We provide a comprehensive 1-year warranty, complete electrical and pneumatic schematics, and permanent remote video troubleshooting support to ensure your workshop maintains continuous production.
Frequently Asked Questions
A: This rotary curing oven is specifically designed to accelerate the curing (drying and polymerization) of polyurethane (PU) foam adhesives after they are cast onto air filter end caps and frames. By providing constant heat, it reduces the curing cycle to under 10 minutes, allowing for continuous assembly line production.
A: Yes. The 60-station turntable features universal, adjustable mechanical jigs and brackets. It can easily accommodate panel air filters, cabin air filters, and cylindrical air filters of various heights and widths.
A: The continuous circular (U-type) design allows for a seamless, closed-loop loading and unloading workflow. A single operator can stand at one station to load raw filters and unload the fully cured finished products, eliminating unnecessary walking, reducing physical labor, and maximizing floor space efficiency.
