Semi-Automatic Honeycomb Air Filter Coiling Machine

This professional Honeycomb Air Filter Coiling Machine is the central winding and assembly unit engineered for manufacturing heavy-duty honeycomb air filters, round vehicle cabin filters, and heavy-duty truck air filter elements. It precisely rolls pre-embossed filter paper or non-woven media into tight, stable circular or oval structural shapes, applying uniform hot-melt adhesive lines during the coiling process to lock the hexagonal cells in place.

Equipped with an automatic tension feedback system, a high-sensitivity touchscreen HMI, and an integrated adhesive dispensing unit, this coiling machine guarantees tight tolerances, uniform density, and robust collapse resistance. It is the ideal machinery for filter factories seeking to automate their air purifier and vehicle intake filter production lines with high efficiency and minimum material waste.

Technical Specifications

To ensure exact mechanical alignment with your honeycomb air filter production line, the technical parameters of the machine are detailed below:

Key Features & Mechanical Advantages

1. Precision Spiral Coiling and Tension Control

The coiler incorporates an advanced pneumatic tension feedback controller that keeps the filter paper flat and consistently tensioned throughout the rolling cycle. This prevents common winding defects such as media wrinkling, air gaps, or “telescoping” inside the finished filter element.

2. Integrated Hot-Melt Adhesive Application

During the coiling process, the integrated dispensing unit applies precise strips of hot-melt glue directly onto the moving filter paper. This ensures that the pleated honeycomb cells bond firmly, significantly improving the mechanical rigidity and pressure resistance of the finished element.

3. Smart Touchscreen HMI Controls

The centralized PLC system enables operators to adjust winding speed, target diameter thresholds, cutting signals, and adhesive dispensing intervals directly on the touchscreen. This digital control simplifies setup and shortens production changeover times between different filter sizes.

4. Robust Construction for Industrial Durability

Built with a rigid, vibration-damping steel frame and chrome-hardened coiling shafts, this machine supports continuous, high-volume production schedules with minimal maintenance requirements and maximum mechanical longevity on the factory floor.

Applications & Industrial Uses

This specialized honeycomb air filter winding machine is the ideal solution for workshops manufacturing:

• Truck and Heavy-Duty Air Filters: Coiling thick, multi-layer honeycomb insert filters designed to withstand extreme engine intake pressures.
• Active Carbon Honeycomb Filters: Winding gas-phase carbon filters for household air purifiers and commercial HVAC units.
• Spin-on Fuel Filter Elements: Coiling paper-based CAV style fuel filters requiring dense and precise structural wrapping.
• Industrial Dust Extraction Elements: Manufacturing specialized cylindrical and conical air intake filters.

Why Partner with Fupei?

• Strict Pre-Shipment Quality Inspections: Every honeycomb coiling machine undergoes continuous running tests with actual filter media at our factory to verify tension and gluing stability before dispatch.
• Custom Voltage Matching: We configure the internal electrical motors, heating elements, and PLC systems to meet your regional industrial standards (such as 3-Phase 380V/50Hz, 220V/60Hz, or 415V/50Hz) for rapid on-site commissioning.
• Global Technical Assistance: We provide a comprehensive 1-year warranty, complete electrical and pneumatic schematics, and permanent remote video troubleshooting support to ensure your workshop maintains continuous production.
