Industrial-grade automatic spiral winding machine designed for oil filter element reinforcement. Equipped with a 5 kg hot melt glue unit (featuring 3 precision nozzles) and a PLC touchscreen interface, it achieves uniform spiral cloth tape winding with stable mechanical tension. Ideal for enhancing oil filter element strength and preventing media deformation in high-pressure oil filtration systems. For integrated panel filter gluing, please view our Automatic Glass Fiber Filter Pleating & Gluing Machine.
This professional Automatic Oil Filter Belt Winding Machine is specifically engineered for the spiral winding of cloth tape around oil filter elements. By reinforcing the outer layer of the filter media, this machine significantly enhances the structural strength of the element, preventing bending or collapsing under high-pressure working conditions, and ultimately extending the filter’s service life.
Equipped with a high-precision PLC touchscreen control system and an integrated hot-melt adhesive dispensing unit, the machine provides uniform tension and smooth adhesive application. It is an indispensable station for manufacturers of automotive spin-on filters, fuel-water separators, and industrial hydraulic filter elements looking to achieve factory-level consistency and structural durability.
Technical Specifications
To ensure exact mechanical alignment with your filter production workshop, the factual technical parameters of the winding machine are detailed below:
Technical Parameters
Factual Specifications
Working Width
1000 mm
Winding Method
Spiral Cloth Tape Winding
Total Power
3.5 kW
Voltage
380V (Customizable to local grid)
Working Air Pressure
0.5 MPa
Glue System
5 kg Hot Melt Glue Machine (with 3 Precision Nozzles)
Control System
PLC Touch Screen
Place of Origin
Hebei, China
Warranty
1 Year
Packaging
Protective Shrink Wrap + Secure Wooden Box
Key Features & Engineering Advantages
1. Uniform Spiral Winding Mechanism
The mechanical rotation chuck is fully synchronized with the tape-feeding guide. This precise alignment ensures consistent overlapping of the cloth tape, providing a uniform reinforcement layer that improves both the structural integrity and the final aesthetic of the oil filter.
2. Integrated 5 kg Hot Melt Glue Unit (3 Nozzles)
The machine features an integrated 5 kg hot melt adhesive unit connected to three precision dispensing nozzles. The glue is applied smoothly and evenly onto the tape as it wraps, securing the reinforcement band tightly without glue leakage or dry spots.
3. Precision Tension Control System
The feeding assembly maintains stable tension on the cloth tape rolls throughout the entire winding cycle. This prevents the tape from slipping, bundling, or wrinkling, ensuring that the filter media remains perfectly supported without distortion.
4. User-Friendly Touchscreen PLC Interface
Operators can program, adjust, and monitor winding speeds, adhesive dispensing intervals, and cycle counts directly on the industrial PLC touchscreen. The system supports multi-recipe storage for quick product changeovers in minutes.
Applications & Industrial Uses
This specialized spiral winding machine is highly utilized in filter assembly lines producing:
Spin-on Oil Filters: Spiral belt reinforcement of automotive and heavy truck engine oil filters.
Fuel-Water Separators: Strengthening diesel fuel filter elements to resist pressure fluctuations.
Industrial Hydraulic Oil Filters: Support wrapping for multi-layer fiberglass hydraulic elements.
Why Partner with Fupei?
Comprehensive Pre-Shipment Testing: Every oil filter winding machine undergoes strict trial runs with actual elements at our facility to guarantee mechanical alignment and gluing stability before shipping.
Global Voltage Support: We configure the internal electrical motors, PLC controllers, and heating elements to match your regional power standards (such as 3-Phase 380V/50Hz, 220V/60Hz, or 415V/50Hz).
Life-Long Technical Assistance: Every machine is supplied with a comprehensive 1-year warranty, complete electrical schematics, and permanent remote video troubleshooting support to keep your production line running smoothly.
Frequently Asked Questions
A: This machine is engineered specifically for reinforcing industrial and automotive oil filter elements that require spiral cloth tape wrapping. For pleating the filter paper media before the winding process, please check our Precision CNC Knife Pleating Machine.
A: The standard working width is 1000 mm, which accommodates a wide range of standard oil filter and separator sizes. We can customize the winding chuck and guide configurations to fit your exact element specifications.
A: The processing speed is fully adjustable and managed digitally via the PLC touch screen, optimized to match high-volume assembly lines while ensuring consistent tension and gluing.
