Industrial 4-station automatic cabin filter edge bonding machine engineered for high-efficiency air filter side border gluing. Features precise hot-melt edge adhesive application for 10–50 mm width and 30–350 mm welt length, driven by a powerful 6.2 kW motor. If your production line also requires continuous filter pleating and inline glue-bead application, please view our Automatic Glass Fiber Filter Pleating & Gluing Machine.
This high-efficiency Automatic Cabin Filter Edge Bonding Machine is specifically engineered for the side edge border gluing of automotive cabin air filters and passenger car climate control filter elements after folding and forming.
By utilizing precise hot-melt adhesive application, the system securely attaches protective non-woven fabric borders or structural adhesive side-strips to the raw edges of the pleated filter paper. This edge-banding process drastically improves the seal integrity, structural rigidity, and overall durability of the finished filter cartridge, preventing air bypass during vehicle HVAC operations. Equipped with an advanced multi-station design and automatic pneumatic cutting, it delivers consistent, professional results with minimum manual labor.
Technical Specifications
To ensure exact mechanical and electrical alignment with your factory standards, the standard technical parameters are detailed below:
Technical Parameters
Factual Specifications
Edge Width
10 – 50 mm
Welt Length
30 – 350 mm
Speed
3 – 4 pcs / minute
Working Air Pressure
0.6 MPa
Motor Power
6.2 kW
Warranty
1 Year
Origin
China
Key Features & Mechanical Advantages
1. High-Yield Four-Station Bonding Design
The machine features four independent working stations that allow for simultaneous adhesive application and setting across multiple filter elements. This clever multi-station design ensures a continuous production workflow, boosting factory output while maximizing station utilization.
2. Precise Automated Edge Gluing & Cutting
Fully integrated edge adhesive application, automatic tape cutting, and wrapping functions ensure uniform gluing quality on every filter side. This precise mechanical calibration guarantees high bonding strength without border misalignment or excess hot-melt adhesive overflow.
3. Touchscreen Control HMI
Equipped with an intuitive touchscreen control panel and integrated PLC, operators can digitally configure edge widths, heating temperatures, cutting speeds, and feed rates on-the-fly, drastically simplifying the on-site product changeover process.
4. Reduced Labor and Production Costs
The automated feeding, gluing, and sealing cycle eliminates the need for tedious manual border pasting and trimming, reducing operator fatigue, minimizing human error, and lowering overall unit production costs.
5. Durable Industrial-Grade Build
Constructed on a heavy-duty, vibration-absorbing structural frame with high-quality pneumatic components and heating elements, the machine is designed to withstand continuous, round-the-clock operation in high-yield manufacturing environments.
Applications & Industrial Uses
This specialized automatic edge-banding equipment is highly utilized by automotive filter factories to produce:
Automotive Cabin Air Filters: Applying structural non-woven fabric side borders to standard and active-carbon cabin filters.
Passenger Car HVAC Elements: Creating tight, leak-free seals on climate control filtration inserts.
Rigorous Factory Testing: Every edge bonding machine is thoroughly tested with actual filter media and hot-melt adhesives before leaving our facility, ensuring flawless out-of-the-box performance.
Custom Voltage Support: We configure the internal electrical elements and hot-melt heating systems to align with your country’s industrial standard (such as 3-Phase 380V/50Hz, 220V/60Hz, or 415V/50Hz).
Full Engineering Schematics: Your machine ships with complete technical wiring diagrams, detailed operations manuals, and lifetime remote video technical support.
Frequently Asked Questions
A: This machine is specifically designed to attach non-woven fabric border tapes or specialized structural adhesive side strips securely to the raw edges of standard pleated cellulose filter paper or synthetic cabin air filter media.
A: The machine operates stably at a speed of approximately 3 to 4 finished filter pieces per minute, depending directly on the technical dimensions of your cabin filters and the setup parameters.
A: The machine requires a stable standard operating air pressure of 0.6 MPa to drive the pneumatic cutting, clamping, and edge-folding mechanisms reliably.
